23m³Liquid Argon Cryogenic Tank Semi Trailer
Hongsen
Shandong, China
20-30days
300 sets/month
Hongsen Trailer 3-axle 23m³Liquid Argon cryogenic tank semi-trailer which to meet the highest chemical transport industry standards, this cutting-edge equipment offers exceptional performance and safety.
23m³Liquid Argon Cryogenic Tank Semi Trailer
Description
Hongsen 3-axle 23m³Liquid Argon Cryogenic Tank Semi-Trailer is designed to optimize your argon transportation needs, ensuring safety, efficiency, and cost-effectiveness.meanwhile equipped with advanced insulation technology to maintain optimal temperatures.
Superior Insulation:Use advanced vacuum-insulated design ensures minimal heat transfer, preserving the integrity of your liquid argon cargo.
Optimized Performance: The powerful 3-axle configuration provides exceptional load-carrying capacity and superior maneuverability.
Safety First: Equipped with multiple safety features, including pressure relief valves, emergency shut-off valves, and advanced monitoring systems, our trailers prioritize the safety of your cargo and personnel.
Specification
Design pressure: 0.8Mpa
Transport medium: liquid argon
Inner Tank Design Temperature: -196℃
Tank Design Temperature: -20℃~+50℃
Dimension: 11500mm * 2500mm *3350mm
Tank Body Material: 5mm Q235 carbon steel
End plate: 5mm Q235 carbon steel
Manhole Cover: Carton steel
Wheelbase: 5550+1310+1310
Suspension: Air suspension
Axle: 3 axles
Tire: 12R22.5
