ZW Group™ Liquid CO2 Tank Semi Trailer

Description

CO2 Tank Semi-Trailers - the ultimate solution for businesses demanding reliable, cost-effective, and eco-friendly CO2 transportation.

Carbon Dioxide Semi-Trailer for sale in Zimbabwe

It used to store and transport compressed carbon dioxide gas in liquid or densified form.  These trailers are commonly used to store or transport CO2 generated from industrial processes, beverage carbonation, food processing, and other applications.

Carbon Dioxide Semi-Trailer for sale in Zimbabwe

The tank body is a single-layer structure,

the external dimension of the tank body (mm):11412×￠2174(including the insulation layer),

the external dimension of the inner tank: 10941×￠1873;

Transport medium: liquid carbon dioxide, unit volume filling capacity of 971 kg/m3

Carbon Dioxide Semi-Trailer for sale in Zimbabwe

The material of the side protection device is aluminum alloy, and the connection mode is bolt connection. The material of the rear protection device is Q235. The rear protection device is replaced by the car body and the height off the ground is 440mm.

Carbon Dioxide Semi-Trailer for sale in Zimbabwe

Enhanced Safety: Equipped with advanced safety features, including pressure relief valves, emergency shut-off systems, and robust insulation, our trailer prioritizes safety without compromising performance.

Optimal Capacity: Our meticulously designed tank maximizes storage capacity, allowing you to transport larger volumes of CO2 in fewer trips, reducing transportation costs and environmental impact.

Efficient Loading and Unloading: Streamlined loading and unloading processes minimize downtime and maximize productivity, keeping your operations running smoothly.

Parameter

Carbon dioxide transport tanker semi trailer

Design pressure: 2.2Mpa

Volume: 28.5 cubic meters

Dimensions: 12500*2500*3550

Wheelbase: 6370+1310+1310

Axles: 3 axles,HONGSEN

Suspension:  mechanical suspension

Tire: 12 units  12PR 11R22.5
